Siemens LOGO! - Ambient mechanical conditions; Electromagnetic compatibility (EMC); Safety to IEC; VDE

LOGO! Manual
A5E00380835-01
268
Criterion ValuesTested in accor-
dance with
Ambient mechanical conditions
Protection mode IP20
Vibrations: IEC 60068-2-6 5 ... 9 Hz (constant
amplitude 3.5 mm)
9 ... 150 Hz (constant
acceleration 1 g)
Shock IEC 60068-2-27 18 shocks
(half-sine wave
15g/11 ms)
Drop IEC 60068-2-31 Drop height 50 mm
Free fall (packaged) IEC 60068-2-32 1 m
Electromagnetic compatibility (EMC)
Noise emission EN 55011/A
EN 55022/B
EN 50081-1
(domestic area)
Limit class B group 1
Electrostatic discharge IEC 61000-4-2
Severity 3
8 kV air discharge
6 kV contact discharge
Electromagnetic fields IEC 61000-4-3 Field strength 10 V/m
HF currents on cables and
cable shielding
IEC 61000-4-6 10 V
Burst pulses IEC 61000-4-4
Severity 3
2 kV (supply and sig-
nal lines)
High-energy surge pulse
(applies only to
LOGO! 230 ...)
IEC 61000-4-5
Severity 3
1 kV (power lines)
symmetrical
2 kV (power lines)
asymmetrical
Safety to IEC / VDE
Clearance and creepage
distance rating
IEC 60664,
IEC 61131-2,
EN 50178
cULus to UL 508,
CSA C22.2 No.
142
With LOGO!
230 R/RC,
also VDE 0631
Fulfilled
Insulation strength IEC 61131-2 Fulfilled
Technical data
