271
LOGO! Manual
A5E00380835-01
LOGO! 230 RC
LOGO! 230 RCo
Input voltage L1
 Signal 0
 Signal 1
 Signal 0
 Signal 1
< 40 V AC
> 79 V AC
< 30 V DC
> 79 V DC
Input current at
 Signal 0 < 0.03 mA
g
 Signal 1 > 0.08 mA
Delay time at
 0 to 1 typ. 50 ms
 1 to 0
yp
typ. 50 ms
Line length (unshielded) 100 m
Digital outputs
Number 4
Output type Relay outputs
Electrical isolation Yes
In groups of 1
Control of a digital input Yes
Continuous current I
th
max. 10 A per relay
Incandescent lamp load
(25000 switching cycles) at
230/240 V AC
115/120 V AC
1000 W
500 W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W
(at 230/240 V AC)
Fluorescent tubes, conven-
tionally compensated (25000
switching cycles)
1 x 58 W
(at 230/240 V AC)
Technical data
