LOGO! Manual
A5E00380835-01
274
LOGO! DM16 230RLOGO! DM8 230R
Input voltage L1
 Signal 0
 Signal 1
 Signal 0
 Signal 1
< 40 V AC
> 79 V AC
< 30 V DC
> 79 V DC
< 40 V AC
> 79 V AC
< 30 V DC
> 79 V DC
Input current at
 Signal 0
 Signal 1
< 0.03 mA
> 0 08 mA
< 0.05 mA
> 0 08 mA

Si
gna
l 1
>
0
.
08
m
A
>
0
.
08
m
A
Delay time at
 0 to 1 typ. 50 ms typ. 50 ms
 1 to 0
yp
typ. 50 ms
yp
typ. 50 ms
Line length (unshielded) 100 m 100 m
Digital outputs
Number 4 8
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
In groups of 1 1
Control of a digital input Yes Yes
Continuous current I
th
max. 5 A per relay max. 5 A per relay
Incandescent lamp load
(25000 switching cycles) at
230/240 V AC
115/120 V AC
1000 W
500 W
1000 W
500 W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W
(at 230/240 V AC)
10 x 58 W (at
230/240 V AC)
Fluorescent tubes, conven-
tionally compensated (25000
switching cycles)
1 x 58 W
(at 230/240 V AC)
1 x 58 W (at
230/240 V AC)
Technical data
