LOGO! Manual
A5E00380835-01
286
LOGO! DM16 24RLOGO! DM8 24 R
Input current at
 Signal 0 < 1.0 mA < 1.0 mA
> 2.0 mA
 Signal 1
> 2.5 mA
> 2
.
0 mA
Delay time at
 0 to 1 typ. 1.5 ms typ. 1.5 ms
 1 to 0 typ. 15 ms typ. 1.5 ms
Line length (unshielded) 100 m 100 m
Digital outputs
Number 4 8
Output type Relay outputs Relay outputs
Electrical isolation Yes Yes
In groups of 1 1
Control of a digital input Yes Yes
Output voltage
Output current
Continuous current I
th
max. 5 A per relay max. 5 A per relay
Incandescent lamp load
(25000 switching cycles) at
1000 W 1000 W
Fluorescent tubes with ballast
(25000 switching cycles)
10 x 58 W 10 x 58 W
Fluorescent tubes, conven-
tionally compensated (25000
switching cycles)
1 x 58 W 1 x 58 W
Fluorescent tubes, uncom-
pensated (25000 switching
cycles)
10 x 58 W 10 x 58 W
Short circuit-proof and over-
load-proof
Technical data
