Detailed description
2.12 Block descriptions
Basic logic functions: PLC Basic program powerline (P3 pl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
225
Description of formal parameters
The table below lists all formal parameters of the SpinCtrl function.
Signal I/O Type Value range Remark
Start I BOOL Start spindle control from PLC
Stop I BOOL Stop spindle control from PLC
Funct I BYTE 1 to B#16#0B 1: Position spindle
2: Rotate spindle
3: Oscillate spindle
4: Indexing axis
5: PosAxis metric
6: PosAxis inch
7: PosAxis metric with handwheel override
8: PosAxis inch with handwheel override
9: Rotate spindle with
automatic gear stage selection
A: Rotate spindle with constant cutting rate
(m/min)
B: Rotate spindle with constant cutting rate
(feet/min)
Mode I BYTE 0 to 5 0: Pos to absolute pos
1: Pos incrementally
2: Pos shortest path
3: Pos absolute, positive approach direction
4: Pos absolute, negative approach direction
5: Rotational direction as for M4
AxisNo I INT 1 - 31 No. of axis/spindle to be traversed
Pos I REAL ∓ 0,1469368 I -38
to
∓ 0,1701412 I +39
Rotary axis: Degrees
Indexing axis: Indexing position
Linear axis: mm or inches
FRate I REAL ∓ 0,1469368 I -38
to
∓ 0,1701412 I +39
Rotary axis and spindle: rev/min
See under table containing info about FRate
InPos Q BOOL 1 = Position reached,
or function executed
Error Q BOOL 1 = Error
State Q BYTE 0 to 255 Error code
FRate
The feed rate in FC 18 can also be specified as:
1. Cutting rate with unit m/min or feet/min
2. Constant grinding wheel surface speed in m/s or feet/s
These alternative velocity settings can be used only if this function is activated by the NC
program. Checkback signals for successful activation can be found in byte 84 on the axis
interface.
