Basic logic functions: PLC Basic program powerline (P3 pl)
226 Function Manual, 11/2006, 6FC5397-0BP10-2BA0
Error identifiers
If a function could not be executed, this is indicated by the "Error" status parameter being set
to 'logical 1'. The error cause is coded at block output "State".
State Description
Errors caused by PLC handling
1 Several axis/spindle functions have been activated simultaneously
20 A function has been started without the position being reached
30 The axis/spindle has been transferred to the NC while still in motion
40 NCK internal error
Errors that occur due to handling of the NCK.
The alarm numbers are described in the Diagnostics Manual SINUMERIK 840D/840Di/810D.
100 corresponds to alarm number: 16830
105 corresponds to alarm number: 16770
106 corresponds to alarm number: 22052
107 corresponds to alarm number: 22051
108 corresponds to alarm number: 22050
109 corresponds to alarm number: 22055
110 Velocity/speed is negative
111 Setpoint speed is zero
112 Invalid gear stage
115 Programmed position has not been reached
117 G96/G961 is not active in the NC
118 G96/G961 is still active in the NC
120 Not an indexing axis
121 Indexing position error
125 DC (shortest path) not possible
126 Minus absolute value not possible
127 Plus absolute value not possible
130 Software limit switch plus
131 Software limit switch minus
132 Working area limitation plus
133 Working area limitation minus
System or other serious interrupts:
200 corresponds to system alarm number: 450007
