Detailed description
2.12 Block descriptions
Basic logic functions: PLC basic program solution line (P3 sl)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
117
SD1 : ANY ;
SD2 : ANY ;
SD3 : ANY ;
SD4 : ANY ;
SD5 : ANY ;
SD6 : ANY ;
SD7 : ANY ;
SD8 : ANY ;
END_VAR
Description of formal parameters
The table below lists all formal parameters of the PUT function.
Signal Typ
e
Type Range of values Remark
Req I BOOL Job start with positive signal edge
NumVar I INT 1 to 8
(corresponds to use of
Addr1 to Addr8)
Number of variables to be written
Addr1 to Addr8 I ANY [DBName].[VarName] Variable identifiers from
NC Var selector
Unit 1 to Unit 8 I BYTE Area address, optional for
variable addressing
Column 1 to Column
8
I WORD Column address, optional for
variable addressing
Line 1 to Line 8 I WORD Line address, optional for variable
addressing
Error A BOOL Negative acknowledgment of job
or execution of job impossible
Done
Q
BOOL Job successfully executed
State
Q
WORD See error identifiers
SD1 to
SD8
I/O ANY P#Mm.n BYTE x...
P#DBnr.dbxm.n BYTE x
Data to be written
