Examples
4.2 Examples 3-6: SETTCOR function for tool environments
Basic logic functions: Tool Offset (W1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
193
Example 5
N10
def real _CORVAL[3]
N20
$TC_DP1[1,1] = 120 ; Milling tool
N30
$TC_DP3[1,1] = 10.0 ; Geometry L1
N40
$TC_DP12[1,1] = 1.0 ; Wear L1
N50
_CORVAL[0] = 0.333
N60
t1 d1 g17 g0
N70
r1 = settcor(_CORVAL, "GW", 0, 3, 0)
N80
t1 d1 x0 y0 z0 ;==> MCS position X0.333 Y0.000
Z11.000
N90
M30
_CORCOMP is 3, as in the previous example, but the compensation is now effective on the
geometry axis with index 0 (X axis). The tool components L3 are assigned to this geometry
axis due to G17 with a milling tool. Calling SETTCOR thus does not affect tool parameters
$TC_DP3 and $TC_DP12. Instead, the compensation value is entered in $TC_DP5.
Example 6
N10
def real _CORVAL[3]
N20
$TC_DP1[1,1] = 500 ; Turning tool
N30
$TC_DP3[1,1] = 10.0 ; Geometry L1
N40
$TC_DP4[1,1] = 15.0 ; Geometry L2
N50
$TC_DP12[1,1]= 10.0 ; Wear L1
N60
$TC_DP13[1,1] =0.0 ; Wear L2
N70
_CORVAL[0] = 5.0
N80
rot y 30
N90
t1 d1 g18 g0
N100
r1 = settcor(_CORVAL, "GW", 0, 3, 1)
N110
t1 d1 x0 y0 z0 ; ==> MCS position X24.330
Y0.000 Z17.500
N120
M30
The tool is a turning tool. A frame rotation is activated in N80, causing the basic coordinate
system (BCS) to be rotated in relation to the workpiece coordinate system (WCS). In the
WCS, the compensation value (N70) acts on the geometry axis with index 1, i.e., on the X
axis because G18 is active. Since "_CORRMODE = 3", the tool wear in the direction of the X
axis of the WCS must become zero once N100 has been executed. The contents of the
relevant tool parameters at the end of the program are thus:
$TC_DP3[1,1]
: 21.830 ; Geometry L1
$TC_DP4[1,1]
: 21.830 ; Geometry L2
$TC_DP12[1,1]
: 2.500 ; Wear L1
$TC_DP13[1,1]
: -4.330 ; Wear L2
