Detailed description
2.7 Program operation mode
Basic logic functions: Mode group, channel, program operation, reset response (K1)
Function Manual, 11/2006, 6FC5397-0BP10-2BA0
139
The significance of the bits of system variable $AC_ASUP is as follows:
Bit Significance
0 User interrupt "ASUB with Blsync"
Continuation: Freely selectable REORG or RET
1 User interrupt "ASUP"; The position at which it was stopped is stored for continuation with
REPOS.
Continuation: Freely selectable REORG or RET
2 User interrupt "ASUB from channel status Ready"
Continuation: Freely selectable REORG or RET
3 User interrupt "ASUB in a manual mode and in channel status Not
Ready"
Continuation: Freely selectable REORG or RET
4 User interrupt "ASUP"; The current position is stored when the interrupt occurs, for
continuation with REPOS.
Continuation: Freely selectable REORG or RET
5 Abortion of subroutine repeat
Continuation: With system ASUB REPOS
6 Activation of decoder single block
Continuation: With system ASUB REPOS
7 Activation of delete distance-to-go
Continuation: With system ASUB RET
8 Activation of axis synchronization
Continuation: With system ASUB REPOS
9 Operating mode switchover
Continuation: On system ASUB REPOS or RET depending on MD11610
10 Program continuation during TEACHIN or after TEACHIN deactivation
Continuation: With system ASUB RET
11 Overstore selection
Continuation: With system ASUB REPOS
12 Alarm with reaction correction block with REPOS
Continuation: With system ASUB REPOS
13 Retraction motion with G33 and stop
Continuation: With system ASUB RET
14 Activation of dry run feedrate
Continuation: With system ASUB REPOS
15 Deactivation of dry run feedrate
Continuation: With system ASUB REPOS
16 Activation of skip block
Continuation: With system ASUB REPOS
17 Deactivation of skip block
Continuation: With system ASUB REPOS
18 Activate machine data
Continuation: With system ASUB REPOS
19 Activate user data
Continuation: With system ASUB REPOS
