SIM5300E AT Command Manual V1.02
<fo> Depending on the Command or result code: first octet of GSM 03.40
SMS-DELIVER, SMS-SUBMIT (default 17), SMS-STATUS-
SMS-COMMAND (default 2) in integer format
<length> integer type value indicating in the text mode (+CMGF=1) the
length of the message body <data>(or <cdata>) in
mode (+CMGF=0), the length of the actual TP data unit in octets (i.e. the RP
layer SMSC address octets are not counted in the length)
<mid> GSM 03.41 CBM Message Identifier in integer format
<oa> GSM 03.40 TP-Originating-Address Address-
Value field in string
format; BCD numbers (or GSM default alphabet characters) are converted
characters of the currently selected TE character set (specified by +CSCS in
3GPP TS 27.007); type of address given by <tooa>
<pdu> In the case of SMS: GSM 04.11 SC address followed by GSM 03.40
TPDU in hexadecimal format: ME/TA converts each octet of TP data unit into
two IRA character long hexadecimal number (e.g. octet with integer value 42
is pres
ented to TE as two characters 2A (IRA 50 and 65)).In the case of CBS:
GSM 03.41 TPDU in hexadecimal format.
<pid> GSM 03.40 TP-Protocol-Identifier in integer format
(default 0)
<sca> GSM 04.11 RP SC address Address-Value field in string format; BCD
nu
mbers (or GSM default alphabet characters) are converted to characters of
the currently selected TE character set (specified by +CSCS in
27.007); type of address given by <tosca>
<scts> GSM 03.40 TP-Service-Centre-Time-Stamp in time-string format
(refer <dt>)
<stat>
0 "REC UNREAD" Received unread messages
1 "REC READ" Received read messages
2 "STO UNSENT" Stored unsent messages
3 "STO SENT" Stored sent messages
4 "ALL" All messages
<toda> GSM 04.11 TP-Destination-Address Type-of-Address octetin integer
format (when first character of <da> is + (IRA 43) default is 145, otherwise
default is 129)
