Trunks
6-8 Strata CIX Programming Vol.1 12/09
01 Line Equipment No. Enter the line equipment number. Equipment numbers are required when
assigning a new line to the system.
Enter data as XXYYZZ:
XX=cabinet 01~12
YY=slot 01~10
ZZ=analog trunk circuit 01~32
Example: If a line should be assigned to an RCOU in cabinet shelf 5, slot 2, circuit
3, enter 050203.
Cabinet numbers:
• CIX/CTX100: Base, Exp.01
• CIX200: Base 01, Exp.02
• CIX670: Base 01, Exp 02~07.
• CIX1200: Base 01, Exp 02~12
Slot numbers:
• CIX/CTX100: Base 01, Exp.05~08
• CIX200: Base/Exp.01~04
• CIX670/1200: Base 01~08
• CIX670/1200: Exp.01~10
CTX28 and CIX40 assignments below are hard coded and cannot be changed.
.
01, 02 - 3 CO lines on motherboard - 28, 40 R1HW, 4 CO lines - 40 R2HW
01, 05 – GVMU - 28, GVPH - 40 R1HW, GIPx, MIPU or GCOCIH - 40 R2HW
01, 06 – GIPx, MIPU16 or GCOCIH - 40 R1HW, no card - 28, 40 R2HW
01, 08 - 3 CO lines on GCDU - 28, 40 R1HW and R2HW.
02 Incoming Line Group Assign the trunk to an Incoming Line Group. Two-way trunks need to be
members of one incoming and one outgoing line group.
Possible values:1~6 CTX28, 1~32 CIX40, 1~32 CTX/CIX/100, 1~50 CTX/CIX
670 BCTU only or BBCU only, 1~128 CTX/CIX670 BCTU +
BEXU or BBCU + BECU, 1~50 CIX1200 HCTU only, 1~128
CIX1200 HCTU + HEXAU, 1~220 CIX1200 HCTU + HEXBU
(default = 0)
03 Outgoing Line Group Assign the trunk to an Outgoing Line Group. Two-way trunks need to be
members of one incoming and one outgoing line group.
Possible values:1~6 CTX28, 1~32 CIX40, 1~32 CTX/CIX/100, 1~50 CIX200,
1~50 CTX/CIX 670 BCTU only or BBCU only, 1~128 CTX/
CIX670 BCTU + BEXU or BBCU + BECU, 1~50 CIX1200 HCTU
only, 1~128 CIX1200 HCTU + HEXAU, 1~220 CIX1200 HCTU +
HEXBU
(default = 0)
F
IELD DESCRIPTION
