Strata CIX Programming Guidelines
Use Default Auto-programming to Start Up
Strata CIX Programming Vol.1 12/09 1-7
Strata CIX
Programming
BIPU-Q1A Initial Programming
After initializing the CIX System with BIPU for Strata Net over IP, Strata CIX detects the BIPU card for
Strata Net over IP and basic programming is set automatically.
Table 1-9 BIPU-Q1A Automatic Settings
Item Description Settings
Card Type Card Type BIPU-Q1A
IP address (BIPU) IP address of BIPU-Q1A In the order of smallest number of the slot
where BIPU is inserted
192.168.254.800 for 1st BIPU
.801 for 2nd BIPU
.802 for 3rd BIPU
Private address will be set
Subnet mask (BIPU) Subnet mask of BIPU-Q1A 255.255.255.0
Default gateway Default gateway of BIPU-Q1A 0.0.0.0
Table 1-10 IP-Trunk Information
Program Description Settings
ILG ILG number 7
Kind of trunk (Analog/ISDN) ISDN
Type of trunk TIE
OLG OLG number 4
Kind of trunk (Analog/ISDN) ISDN
Type of trunk TIE
ISDN trunk CG number 1: 1st BIPU-Q
2: 2nd BIPU-Q
3: 3rd BIPU-Q
Type of protocol IP
ILG 7
OLG 4
Voice coding procedure CODEC (G.711, G.729A) G.711
Index of Voice attribute table (1~256) 1
Parameter of voice attribute
table
- Packet Interval: 20ms
Type of Jitter buffer: Fixed
Size of Jitter buffer: 1
Max Acceptable Delay: 1
Measure Time: 1000ms
Packet Loss Ratio: 5
Packet Discard Ratio: 5
