Trunks
Trunk DID/DNIS Setup Wizard
6-44 Strata CIX Programming Vol.1 12/09
Step 2: Create or Delete DID/DNIS Numbers for ILG 2
1. From Step 2: 309 Create or Delete DID/DNIS Numbers for ILG 2 screen click Create to create a block
of DID/DNIS numbers. The numbers are created in consecutive order.
Create DID/DNIS Numbers screen displays.
• Specify the first number in the DID/DNIS block.
Note The quantity of digits must match the quantity of digits assigned to the selected ILG (refer back to
DID/DNIS Digit Length on the previous screen).
• Specify the DID/DNIS Number block size that should be created. This is the quantity of DID/DNIS
numbers ordered from the DID/DNIS provider.
• Specify “overwrite existing” or “add to existing” DID/DNIS numbers. If no DID/DNIS numbers exist,
add or overwrite is OK or click Delete and the delete DID/DNIS number dialog box displays. Specify
the first and last DID/DNIS number to delete using the drop-down boxes or check mark Delete all
DID/DNIS numbers. Click Delete Now. The numbers are deleted.
CAUTION! Overwrite erases all existing DID/DNIS numbers currently programmed for the
selected ILG.
2. (Optional) Click DID/DNIS Table View to view existing DID/DNIS assignments. For more details see
“DID/DNIS Table View” on page 6-25.
3. When finished click Next.
Step 3: Assign DID/DNIS Number Audio Destinations for ILG 2
1. From Step 3: 309 Assign DID/DNIS Number Audio Destinations for ILG 2 screen set the DID/DNIS
Number range.
Note This step enables you to assign the ringing destinations for all DID/DNIS numbers in the selected
ILG. This assignment applies only to voice (audio) calls—not to data calls.
2. Specify the range of DID/DNIS numbers for which ringing assignments should be made. Use the First
Number/Last Number drop-down arrows.
3. Fill in the appropriate fields on this screen (see field descriptions below).
4. (Optional) Click DID/DNIS Table View to view existing DID/DNIS assignments. For more details, see
“DID/DNIS Table View” on page 6-25.
5. After selecting DID/DNIS ringing destination assignments click Submit to register them in the CIX
database.
6. After creating DID/DNIS ringing destinations click Next to assign DID/DNIS Voice Mail ID codes. These
VM codes are optional and are only used if DID/DNIS numbers have unique VM boxes to “call forward
to” or “ring directly to.”
To Next Page
