Trunks
Trunk DID/DNIS Setup Wizard
6-46 Strata CIX Programming Vol.1 12/09
Step 4: Assign DID/DNIS VMID Codes for ILG
1. From Step 4: Assign DID/DNIS Number VMID Codes for ILG 2 screen, assign VMID codes for all DID/
DNIS numbers in the selected ILG. See field descriptions below.
2. (Optional) Click DID/DNIS Table View to view existing DID/DNIS assignments. For more details
see “DID/DNIS Table View” on page 6-25.
3. After selecting VMID code assignments click Submit to register them in the CIX database.
F
IELD DESCRIPTION
Set for DID/DNIS Number
Range:
Specify the range of DID/DNIS numbers for which VMID code assignments should
be made. Use the First Number/Last Number drop down arrows.
Set for: The codes can be set independently for DTMF in band or SMDI Voice Mail
integration.
DTMF VMID Select to set VMID code assignments for DTMF voice mail integration.
SMDI VMID Select to set VMID code assignments for SMDI voice mail integration.
All Select to set VMID code assignments for DTMF and SMDI voice mail integration.
Note
DTMF and SMDI Voice Mail integration will not function simultaneously on the
CIX.
Set the VMID Range Select the method in which VMID codes should be created:
Use DNIS as VMID - the VMID code for each DID/DNIS number will be the same
as the DID/DNIS number.
Start with - enter the VMID that should be assigned to the first selected DID/DNIS
number. VMID codes will be assigned consecutively, starting with this code, to
each consecutive DID/DNIS number.
Only Use - all selected DID/DNIS numbers will be assigned to the VMID code
entered here.
Add to front - these digits will be added in front of each VMID code.
Add to end - these digits will be added to the end of each VMID code.
