IP Telephone Programming
IP Telephone Installation and Network Connection Setup
8-14 Strata CIX Programming Vol.1 12/09
01 IPU IP Address Enter the MIPU/LIPU/GIPx IP Address.
Possible values:XXX.XXX.XXX.XXX where XXX = 0 ~ 255
02 IPU Subnet Address Enter the Subnet Mask of the MIPU/LIPU/GIPx.
Possible values:XXX.XXX.XXX.XXX where XXX = 0 ~ 255
03 IPU Default Gateway
Address
Enter the Default Gateway Address of the MIPU/LIPU/GIPx card.
Possible values:XXX.XXX.XXX.XXX where XXX = 0 ~ 255
04 LIPS IP Address Enter the second LIPU IP Address. The second LIPU IP address must be within
the subnet address. Not used for MIPU/GIPx.
Possible values:XXX.XXX.XXX.XXX where XXX = 0 ~ 255
05 LIPS Subnet
Address
Enter the Subnet Mask of the second LIPU. Not used for MIPU/GIPx.
Possible values:XXX.XXX.XXX.XXX where XXX = 0 ~ 255
06 LIPS Default
Gateway Address
Enter the Default Gateway Address of the second LIPU. Not used for MIPU/GIPx.
Possible values:XXX.XXX.XXX.XXX where XXX = 0 ~ 255
07 Version of IPU/IPH Firmware version of MIPU/GIPx/LIPU is displayed.
Possible values:Max 16 characters
Possible values:For IPU 15 digits:
IPUXX_XXY_AZXX
IPUXX_XX: firmware version
Y: Boot loader version
AZXX: DSP Configuration File
A= Country
Z=Major version 0~ 9
XX=Minor version 00 ~ 99
08 Version of LIPS Firmware version of LIPS-X is shown.
Possible values:Max 16 characters
09 Available IPU/IPH IP
Ports
Number of available IP ports in MIPU/GIPU/LIPU-X is shown. When speaker OCA
is assigned to an IP telephone an additional IP port is assigned to the IP telephone.
If there is no available IP port in the LIPU-X, no more IP telephone/SIP/Strata Net
IPs can be assigned.
Possible values:0~24 (MIPU24), 0~16 (MIPU16, LIPU, LIPS), 0~8 (GIPx)
10 Available LIPS IP
Ports
Number of available IP ports in LIPS is shown. When speaker OCA is assigned to
an IP telephone an additional IP port is assigned to the IP telephone. If there is no
available IP port in the LIPS, no more IP telephone/SIP/Strata Net IPs can be
assigned.
Possible values:0 ~ 16
11 IPU/IPH Packet
Prioritization
Enable or Disable Packet Prioritization
Possible values:Enable, Disable
The default value is: Disable
F
IELD DESCRIPTION
