T703 Interconnect List
(Reference: 073600100A DCN5882)
Cable Part
#
Signal Assembly PN J/P Pin Assembly PN J/P Pin
0364901 CBL, AC Power, E-series
AC Line Power Entry CN0000073 L Power Switch SW0000025 L
AC Neutral Power Entry CN0000073 N Power Switch SW0000025 N
Power Grnd Power Entry CN0000073 Shield SW0000025
Power Grnd Power Entry CN0000073 Chassis 052590000
AC Line Switched Power Switch SW0000025 L PS2 (+12) 068020000 J1 1
AC Neutral Switched Power Switch SW0000025 N PS2 (+12) 068020000 J1 3
Power Grnd Power Entry CN0000073 PS2 (+12) 068020000 J1 2
AC Line Switched Power Switch SW0000025 L PS1 (+5, ±15) 068010000 J1 1
AC Neutral Switched Power Switch SW0000025 N PS1 (+5, ±15) 068010000 J1 3
Power Grnd Power Entry CN0000073 PS1 (+5, ±15) 068010000 J1 2
AC Line Switched Power Switch SW0000025 L Relay Board 045230100 J1 1
AC Neutral Switched Power Switch SW0000025 N Relay Board 045230100 J1 3
Power Grnd Power Entry CN0000073 Relay Board 045230100 J1 2
03829 CBL, DC Power to Motherboard
DGND Relay Board 045230100 J7 1 Motherboard 058021400 J15 1
+5V Relay Board 045230100 J7 2 Motherboard 058021400 J15 2
AGND Relay Board 045230100 J7 3 Motherboard 058021400 J15 3
+15V Relay Board 045230100 J7 4 Motherboard 058021400 J15 4
AGND Relay Board 045230100 J7 5 Motherboard 058021400 J15 5
-15V Relay Board 045230100 J7 6 Motherboard 058021400 J15 6
+12V RET Relay Board 045230100 J7 7 Motherboard 058021400 J15 7
+12V Relay Board 045230100 J7 8 Motherboard 058021400 J15 8
Chassis Gnd Relay Board 045230100 J7 10 Motherboard 058021400 J15 9
04105 CBL, Keyboard to Motherboard
Kbd Interupt LCD Interface PCA 066970000 J1 7 Motherboard 058021400 J106 1
DGND LCD Interface PCA 066970000 J1 2 Motherboard 058021400 J106 8
SDA LCD Interface PCA 066970000 J1 5 Motherboard 058021400 J106 2
SCL LCD Interface PCA 066970000 J1 6 Motherboard 058021400 J106 6
Shld LCD Interface PCA 066970000 J1 10 Motherboard 058021400 J106 5
041760000 CBL, DC Power, EOS
DGND Relay Board 045230100 J8 1 PS1 (+5, ±15) 068010000 J2 3
+5V Relay Board 045230100 J8 2 PS1 (+5, ±15) 068010000 J2 1
+15V Relay Board 045230100 J8 4 PS1 (+5, ±15) 068010000 J2 6
AGND Relay Board 045230100 J8 5 PS1 (+5, ±15) 068010000 J2 4
-15V Relay Board 045230100 J8 6 PS1 (+5, ±15) 068010000 J2 5
+12V RET Relay Board 045230100 J8 7 PS2 (+12) 068020000 J2 3
+12V Relay Board 045230100 J8 8 PS2 (+12) 068020000 J2 1
042790100 CBL, Heater/Thermistor
+12V RET Relay Board 045230100 J19 1 Lamp HTR/Thrm 041440000 1
+12V Relay Board 045230100 J19 2 Lamp HTR/Thrm 041440000 2
+5VANA Motherboard 058021400 J27 6 Lamp HTR/Thrm 041440000 3
THERMISTOR 3 Motherboard 058021400 J27 13 Lamp HTR/Thrm 041440000 4
+5VANA Motherboard 058021400 J27 7 Sample Therm 042010000 1
THERMISTOR 2 Motherboard 058021400 J27 14 Sample Therm 042010000 2
THERMISTOR 4 Motherboard 058021400 J27 12 O3 Gen HTR/Therm 041440100 6
+5VANA Motherboard 058021400 J27 5 O3 Gen HTR/Therm 041440100 5
+12V RET Relay Board 045230100 J14 2 O3 Gen HTR/Therm 041440100 2
+12V Relay Board 045230100 J14 1 O3 Gen HTR/Therm 041440100 1
CONNECTION FROM CONNECTION TO
