T703 Interconnect List
(Reference: 073600100A DCN5882)
Cable Part
#
Signal Assembly PN J/P Pin Assembly PN J/P Pin
CONNECTION FROM CONNECTION TO
042800100 CBL, Power & Signal Distribution
CH1 Motherboard 058021400 J109 6 UV Det - Bench 041200000 P3 1
AGND Motherboard 058021400 J109 12 UV Det - Bench 041200000 P3 4
+15V Relay Board 045230100 J5 4 Bench Lamp Supply 041200000 P3 2
-15V Relay Board 045230100 J5 6 Bench Lamp Supply 041200000 P3 3
+12V RET Relay Board 045230100 J5 7 Fan 040010000 P1 1
+12V Relay Board 045230100 J5 8 Fan 040010000 P1 2
CH6 Motherboard 058021400 J109 2 Photo Press/Flo 040030700 P1 4
CH4 Motherboard 058021400 J109 3 Photo Press/Flo 040030700 P1 2
CH7 Motherboard 058021400 J109 1 Photo Press/Flo 040030700 P1 5
AGND Relay Board 045230100 J9 3 Photo Press/Flo 040030700 P1 3
+15V Relay Board 045230100 J9 4 Photo Press/Flo 040030700 P1 6
DGND Relay Board 045230100 J9 1 LCD Interface PCA 066970000 J14 8
VCC Relay Board 045230100 J9 2 LCD Interface PCA 066970000 J14 1
DGND Relay Board 045230100 J12 1 LCD Interface PCA 066970000 J14 2
VCC Relay Board 045230100 J12 2 LCD Interface PCA 066970000 J14 3
+15V Relay Board 045230100 J12 4 IZ Det 041200000 P3 2
-15V Relay Board 045230100 J12 6 IZ Det 041200000 P3 3
CH2 Motherboard 058021400 J109 5 IZ Det 041200000 P3 1
AGND Motherboard 058021400 J109 11 IZ Det 041200000 P3 4
04671 CBL, Motherboard to Transmitter Board (Multidrop Option)
GND Motherboard 058021400 P12 2 Xmitter bd w/Multidrop 069500000 J4 2
RX0 Motherboard 058021400 P12 14 Xmitter bd w/Multidrop 069500000 J4 14
RTS0 Motherboard 058021400 P12 13 Xmitter bd w/Multidrop 069500000 J4 13
TX0 Motherboard 058021400 P12 12 Xmitter bd w/Multidrop 069500000 J4 12
CTS0 Motherboard 058021400 P12 11 Xmitter bd w/Multidrop 069500000 J4 11
RS-GND0 Motherboard 058021400 P12 10 Xmitter bd w/Multidrop 069500000 J4 10
RTS1 Motherboard 058021400 P12 8 Xmitter bd w/Multidrop 069500000 J4 8
CTS1/485- Motherboard 058021400 P12 6 Xmitter bd w/Multidrop 069500000 J4 6
RX1 Motherboard 058021400 P12 9 Xmitter bd w/Multidrop 069500000 J4 9
TX1/485+ Motherboard 058021400 P12 7 Xmitter bd w/Multidrop 069500000 J4 7
RS-GND1 Motherboard 058021400 P12 5 Xmitter bd w/Multidrop 069500000 J4 5
RX1 Motherboard 058021400 P12 9 Xmitter bd w/Multidrop 069500000 J4 9
TX1/485+ Motherboard 058021400 P12 7 Xmitter bd w/Multidrop 069500000 J4 7
RS-GND1 Motherboard 058021400 P12 5 Xmitter bd w/Multidrop 069500000 J4 5
054840000 CBL, Valve Driver & Pump Power
+12V Relay Board 045230100 J4 1 Photo Ref Valve 055220000 1
+12V RET Relay Board 045230100 J4 2 Photo Ref Valve 055220000 2
+12V Relay Board 045230100 J4 3 O3 Valve 055220000 1
+12V RET Relay Board 045230100 J4 4 O3 Valve 055220000 2
+12V Relay Board 045230100 J4 5 Pump 047020000 1
+12V RET Relay Board 045230100 J4 6 Pump 047020000 2
056310100 CBL, I2C Signal
+15V IZS Lamp Supply 041660100 P1 1 Relay Board 045230100 J5 4
AGND IZS Lamp Supply 041660100 P1 2 Relay Board 045230100 J5 3
SCL IZS Lamp Supply 041660100 P1 3 Relay Board 045230100 J3 1
SDA IZS Lamp Supply 041660100 P1 4 Relay Board 045230100 J3 2
Shield Motherboard 058021400 J107 6 Relay Board 045230100 J3 5
SCL IZS Lamp Supply 041660100 P1 3 Bench Lamp Supply 041660500 P1 3
SDA IZS Lamp Supply 041660100 P1 4 Bench Lamp Supply 041660500 P1 4
SCL Motherboard 058021400 J107 3 Bench Lamp Supply 041660500 P1 3
SDA Motherboard 058021400 J107 5 Bench Lamp Supply 041660500 P1 4
+15V Relay Board 045230100 J10 4 Bench Lamp Supply 041660500 P1 1
AGND Relay Board 045230100 J10 3 Bench Lamp Supply 041660500 P1 2
05673 CBL, Pump Adapter
115VAC Relay Board 045230100 J2 1 Pump 037070000 1
230VAC Relay Board 045230100 J2 5 Pump 037070000 2
Neutral Relay Board 045230100 J2 2 Pump 037070000 3
Jumper Relay Board 045230100 J2 3 Relay Board 045230100 J2 4
06737 CBL, I2C to AUX I/O (Analog In Option)
ATX- Motherboard 058021400 J106 1 Aux I/O PCA 067300000 J2 1
ATX+ Motherboard 058021400 J106 2 Aux I/O PCA 067300000 J2 2
LED0 Motherboard 058021400 J106 3 Aux I/O PCA 067300000 J2 3
ARX+ Motherboard 058021400 J106 4 Aux I/O PCA 067300000 J2 4
ARX- Motherboard 058021400 J106 5 Aux I/O PCA 067300000 J2 5
LED0+ Motherboard 058021400 J106 6 Aux I/O PCA 067300000 J2 6
LED1+ Motherboard 058021400 J106 8 Aux I/O PCA 067300000 J2 8
To Next Page
