TH2829X Series Operation Manual Chapter 8 Performance and Test
The basic measurement accuracy factor A can be obtained by the following
methods:
In figure A, two values of basic measurement accuracy A are included in each
frame. For example, the two values in the middle frame are 0.05(top) /
0.1(bottom).
When the test speed is MEDIUM or SLOW, select the value in the top, such as
0.05.
