Toro Groundmaster Series - Page 79

g296816
Figure16
1.Fuelhose,return
5.Elbowtting(2each)9.Clamp(3each)
2.Fuelhose,pumptolter
6.Fuelhose,supply
10.Clamp
3.Fuelpump7.Fuelhose,separatortopump11.Fuelcooler
4.Separatorhead8.Separatorelement12.Fuelhose,ltertocooler
Thefuelsystemincludesafueltankwithamechanicalfuellevelgaugeonthe
leftsideofthemachine,afuel/waterseparator,alowpressureelectricfuelpump,
andafuellterandmechanicalhighpressurefuelinjectionpumplocatedonthe
engine.Model31902/31903machinesincludeafuelcoolerlocatedinfront
oftheradiatorandhydraulicuidcoolerassembly.Fortestingproceduresfor
thelowpressureelectricfuelpump;refertoTestingtheElectricalComponents
(page6–9).
DANGER
Dieselfuelishighlyammableandexplosive.Areoranexplosion
fromthefuelcanburnyou,burnotherpeople,anddamageproperty.
•Usecautionwheneveryoustoreorhandledieselfuel.
•Donotsmokewhilehandlingdieselfuel.
•Donothandledieselfuelwhiletheengineisrunning,whilethe
engineishot,orwhenthemachineisinanenclosedarea.
•Handledieselfueloutsidewheneverpossibleandwipeupany
spilleddieselfuelbeforestartingtheengine.
•Storefuelinaclean,safety-approvedcontainerandkeepthecap
inplace.
•Usedieselfuelasanenginefuelonly,notforanyotherpurpose.
CheckingtheFuelLinesandConnections
Checkthefuellinesandconnectionsatthescheduledmaintenanceintervals
recommendedinthetractionunitOperator'sManual.Checkthelinesfor
deterioration,damage,leaks,orlooseconnections.Replacethehoses,clamps,
andttingsifnecessary;refertoFigure16.
Groundsmaster
®
3200,3300and3310
Page4–17
Engine:ServiceandRepairs
19240SLRevA
