Toro TX525 - Starter Installation

ENGINE
4-52 Rev. 000 TX525 Service Manual
14. Removethe2startermountingboltsandlock-
washerssecuringthestartertotheengineblock
(Fig.0267).
Fig 0267 PICT-5198
15. Removethestarterassembly(Fig.0268).
Fig 0268 PICT-5202
Starter Installation
16. Toservicethestarterreferto“StarterAssembly
Teardown”onpage4-171(Fig.0269).
Fig 0269 PICT-5203a
1. Positionthestarterassemblytotheengineblock
(Fig.0270).
Fig 0270 PICT-5202
