Toro TX525 - Throttle Cable Adjustment

ENGINE
4-142 Rev. 000 TX525 Service Manual
Throttle Cable Adjustment
1. Raisethehood.
2. Removetherighthandsidepanel(Fig.0617).
Fig 0617 PICT-8759
3. Movetheairintakehoseoutofthewayofthe
throttleplate.Usinga1/4”wrench,loosenthe
throttlecableswivel(Fig.0618).
Fig 0618 PICT-7140
4. Thereshouldbeapproximately3/16”to1/4”(0.48to
0.635cm)ofcablethroughtheswivel(Fig.0619).
Fig 0619 PICT-7107
5. Toadjusttheamountofcablegoingthroughthe
swivel(Fig.0620):
a. Usingtwo7/16”wrenches,loosenthetwo
adjustingnutssecuringthecabletothethrottle
bracket.
b. Toshortenthecable:threadthenutstowardthe
cableend.
c. Tolengthenthecable,threadthenutsfurther
onto the cable.
Fig 0620 PICT-7113
