Toro TX525 - Fuel Tank Removal

MAINTENANCE
3-19TX525 Service Manual Rev. 000
Fuel Tank Removal
1. Parkthemachinesothatthetracksarerestingon
2x4s.
2. Openthehood.Raisetheloaderarms,installthe
cylinderlock,stoptheengineandremovethekey.
3. Applytheparkingbrake.
3. Removetherearaccesspanel(Fig.0051).
5. Using3/4”and1/2”sockets,removethe7boltsand
nutssecuringtherearframecovertotheframeand
fueltankbracket.Removetherearframecover(Fig.
0053).
Fig 0051 PICT-4505a
Fig 0053 PICT-5381
4. Usinga3/8”socket,removethe6screwsthatse-
curetheleftandrightrearcoversupportpanelsto
thetowerassembly(3screwsperpanel).Remove
thepanels(Fig.0052).
Fig 0052 PICT-8934
