Toro TX525 - Engine Component Removal

ENGINE
4-87TX525 Service Manual Rev. 000
100. Usinga17mmsocket,removethe5screwsse-
curingthelefthandenginemounttotheengine
(Fig.0402).
Fig 0402 PICT-5495
101. Removethelefthandenginemountfromthe
engine(Fig.0403).
Fig 0403 PICT-5497
Engine Component Removal
102. Transfertheenginefromtheenginehoisttoan
enginestand(Fig.0404).
Fig 0404 PICT-5498
1. Usinga10mmsocket,removethescrewsecuring
thestarterbafeplatetotheexhaustmanifold(Fig.
0405).
Fig 0405 PICT-5499
