Toro TX525 - Radiator & Oil Cooler Assembly Installation

ENGINE
4-15TX525 Service Manual Rev. 000
10. Looselyinstall2bolts,washersandnutssecuring
thefanshroudtotheradiator/oilcoolerassembly
(Fig.0131).
12. Installtheradiator/oilcoolerassemblyintothema-
chine.Referto“RadiatorandOilCoolerAssembly
Installation”following.
Fig 0131 PICT-5109
1. Inspectthefoamsealslocatedinsidetheframe.Re-
placeifwornordamaged(Fig.0133).
11. Tightenthe4boltssecuringthefanshroudtothe
radiator/oilcoolerassembly(Fig.0132).
Fig 0133 PICT-5110
Fig 0132 PICT-5111a
Radiator & Oil Cooler Assembly Installation
