Toro TX525 - Changing Engine Coolant Assembly

MAINTENANCE
3-14 Rev. 000 TX525 Service Manual
6. Positiontheradiatormountintotheframe(Fig.
0036).
3. Removethedrainhoseandclosethepetcock.
4. Positiontheradiator/oilcoolerassemblyintothe
framesoitisontopofthefoamsealsandbehind
the3radiatormountholes(Fig.0034).
Fig 0036 PICT-5129
Fig 0034 PICT-5122
Changing Engine Coolant Assembly
5. Using1-1/16”and1-1/8”wrenches,installthehy-
draulicoutletlinetotheoilcooleroutlettting(Fig.
0035).
1. Cleananydebrisaroundandundertheradiator.
2. Usinga17mmwrenchinstalltheengineblock
coolantdrainplug(Fig.0033).
Fig 0035 PICT-5126
Fig 0033 PICT-8910
