MAINTENANCE
3-15TX525 Service Manual Rev. 000
7. Looselyinstall3screwsthatwillsecuretheradiator
mounttotheframe(Fig.0037).
9. Withoutmovingthepositionoftheradiator,slidethe
radiatormountagainsttheradiatorandtightenthe3
radiatormountscrews(Fig.0039).
Fig 0037 PICT-5131
Fig 0039 PICT-5137
10. Positionthegrillontotheframeandroutethebreath-
ertubeinbetweenthefoamsealsontheinnerleft
sideofthegrill(Fig.0040).
8. Centertheradiatorandoilcoolerassemblysideto
sideintheframesothereisapproximatelya1/8”
spacebetweenthefanshroudandthefan.Spin
thecoolingfan.Ensurethefandoesnotcomeinto
contactwiththefanshroud.Adjusttheradiatorside
tosideasnecessary(Fig.0038).
Fig 0040 PICT-5139
Fig 0038 PICT-5135
