Toro TX525 - Greasing the Traction Unit

MAINTENANCE
3-2 Rev. 000 TX525 Service Manual
(4)arelocatedontherightside(Fig.0002).
Fig 0002 PICT-8729a
(4)arelocatedinthefrontonthequickattachment
assemblyandthefrontloaderarmassembly(Fig.0003).
Fig 0003 PICT-8730
Greasing the Traction Unit
Greaseallpivotjointsevery8operatinghoursand
immediatelyaftereverywashing.
GreaseType:LithiumbasedNLGI2
1. Lowertheloaderarmandstoptheengine.Remove
thekeyfromtheignitionswitch.
2. Cleanthegreasettingswitharag.
3. Connectgreaseguntoeachttingandpumpgrease
intothettingsuntilgreasebeginstooozeout
(approximately3pumps).
4. Wipeanyexcessgrease.
Thereare12greasettingsontheTX525:
(4)arelocatedontheleftside(Fig.0001).
Fig 0001 PICT-8726a
