Toro TX525 - Starter Assembly Teardown

ENGINE
4-171TX525 Service Manual Rev. 000
Starter Assembly Teardown
1. Securethestarterinavise(Fig.0724).
3. Removethejumperwireringterminalandthestarter
wirefromthemagneticswitchterminal(Fig.0726
andFig.0727).
Fig 0724 PICT-8018a
Fig 0726 PICT-8022a
2. Usinga12mmsocket,removethenutfromthe
magneticswitchterminal(Fig.0725).
Fig 0727 PICT-8024a
Fig 0725 PICT-8019a
