23. Slidethepulleyontothealternatorshaft(Fig.0722).
Fig 0722 PICT-8268a
24. Usinga22mmsocketandastrapwrench,install
anutontothealternatorshafttosecurethepulley.
Torquethenutto43.0to58.2ft-lbs.(58.3to78.9
Nm)(Fig.0723).
22. Slideacollarontothealternatorshaft(Fig.0721).
Fig 0723 PICT-8270a
Fig 0721 PICT-8267a
