Toro TX525 - Specifications; General Specifications; Dimensions

2-1TX525 Service Manual Rev. 000
SPECIFICATIONS
General Specications
Item Specication
Engine Domestic:
22319 Ser #270000001 - 280999999 / D902E2B
22320 Ser #270000001 - 280999999 / D902E2B
International:
22333 Ser #270000001 - 280999999 / D902E2B
22334 Ser #270000001 - 280999999 / D902E2B
RPM Setting Domestic:
No-load Speed – 3670 rpm +20/-50 rpm
Low idle Speed – 1600 rpm ± 100 rpm
International:
No-load Speed – 3200 rpm +75/-50 rpm
Low idle Speed – 1600 rpm ± 50 rpm
Oil Capacity 3.84 quarts (3.63 liters) with lter
Fuel Tank 6 gallons (22.7 liters)
TX525 Narrow Track TX525 Wide Track
Overall Length, without Bucket 70.7” (179.6cm) 70.7” (179.6cm)
Overall Length, with Bucket 92” (233.7cm) 92” (233.7cm)
Overall Width 33.7” (85.6cm) 41” (104.1cm)
Overall Height 46.1” (117.1cm) 46.1” (117.1cm)
Overall Operating Height, Fully Raised 90.1” (228.9cm) 90.1” (228.9cm)
Reach, Fully Raised 21.8” (55.4cm) 21.8” (55.4cm)
Reach Maximum 37” (94cm) 37” (94cm)
Dump Angle 38º 38º
Dump Height 46.1” (117.1cm) 46.1” (117.1cm)
Bucket Rollback, Ground Position 23º 23º
Bucket Rollback, Carry Position 23º 23º
Bucket Rollback, Fully Raised 85º 85º
Wheel Base 31.1” (79cm) 31.1” (79cm)
Ground Clearance Maximum 4.6” (11.7cm) 4.6” (11.7cm)
Dimensions
