Toro TX525 - Other Torque Specifications

2-8 Rev. 000 TX525 Service Manual
SPECIFICATIONS
SPECIFICATIONS
TimeCutter
®
Z Service Manual 2 - 7
Other Torque Specifications
SAE Grade 8 Steel Set Screws
Thread Cutting Screws
(Zinc Plated Steel)
Conversion Factors
in-lb X 11.2985 - N-cm
ft-lb X 1.3558 = N-m
Wheel Bolts and Lug Nuts
** For steel wheels and non-lubricated fasteners.
Thread Cutting Screws
(Zinc Plated Steel)
* Hole size, material strength, material thickness and
finish must be considered when determining specific
torque values. All torque values are based on non-
lubricated fasteners.
N-cm X - 0.08851 = in-lb
N-cm X 0.73776 - ft-lb
Thread Size
Recommended Torque
Square Head Hex Socket
1/4 - 20 UNC 140 ± 20 in-lb 73 ± 12 in-lb
5/16 - 18 UNC 215 ± 35 in-lb 145 ± 20 in-lb
3/8 - 16 UNC 35 ± 10 ft-lb 18 ± 3 ft-lb
1/2 - 13 UNC 75 ± 15 ft-lb 50 ± 10 ft-lb
Type 1, Type 23, or Type F
Thread Size Baseline Torque*
No. 6 - 32 UNC 20 ± 5 in-lb
No. 8 - 32 UNC 30 ± 5 in-lb
No.10 - 24 UNC 38 ± 7 in-lb
1/4 - 20 UNC 85 ± 15 in-lb
5/16 - 18 UNC 110 ± 20 in-lb
3/8 - 16 UNC 200 ± 100 in-lb
Thread Size Recommended Torque**
7/16 - 20 UNF
Grade 5
65 ± 10 ft-lb 88 ± 14 N-m
1/2 - 20 UNF
Grade 5
80 ± 10 ft-lb 108 ± 14 N-m
M12 X 1.25
Class 8.8
80 ± 10 ft-lb 108 ± 14 N-m
M12 X 1.5
Class 8.8
80 ± 10 ft-lb 108 ± 14 N-m
Thread
Size
Threads per Inch
Baseline Torque*
Type A Type B
No. 6 18 20 20 ± 5 in-lb
No. 8 15 18 30 ± 5 in-lb
No. 10 12 16 38 ± 7 in-lb
No. 12 11 14 85 ± 15 in-lb
Other Torque Specications
