HYDRAULIC SYSTEM
6-42 Rev. 000 TX525 Service Manual
Hydraulic Tandem Pump Rebuild
15. Install the rear access panel (Fig. 0988).
Fig 0988 PICT-4505
Note: Cleanliness is a key factor in a successful
repair of any hydraulic system. Thoroughly
clean all exposed surfaces prior to any type
of maintenance. Cleaning all parts by using
a solvent wash and air drying is usually
adequate. As with any precision equipment,
all parts must be kept free of foreign material
and chemicals. Protect all exposed sealing
areas and open cavities from damage and
foreign material.
Upon removal, all seals, o-rings, and gaskets
should be replaced. During installation, lightly
lubricate all seals, o-rings, and gaskets with
clean oil prior to assembly.
1. Remove the key from the keyway of the pump shaft
Fig. 0989).
16. Lower the machine.
Fig 0989 PICT-2823a
