Toro TX525 - Hydraulic System Cont; Electrical System; Track System

2-4 Rev. 000 TX525 Service Manual
SPECIFICATIONS
Electrical System
Hydraulic System cont.
Track System
Item Specication
Battery 12 volt, BCI group 55 battery with 585 CCA
Gauges The control panel contains hour meter, fuel gauge, glow plug control, water temp,
electrical charge and oil pressure.
Fuel System Electric frame mounted pump
Ignition The ignition switch is panel mounted with STOP-RUN-START positions.
Fuses The machine has a fuse block with 2 separate fuses, 10 and 30 amp.
Item Specication
Tank The hydraulic tank is a fabricated weldment integrated into the main frame. The tank has
a cleanout access, stainless screens at the ll and suction ports and a remote breather
connected via hose.
Capacity: 10.5 gallons (39.7 liters)
Filter In addition to the in-tank screens, the loader circuit passes through a 10 micron spin-on lter
prior to returning to tank.
Item Specication
Track The tracks are Kevlar reinforced, endless rubber rings with 28 internal drive lugs. The outer
tread on the tracks is a turf-friendly S-shaped pattern with pitched crosscuts.
Track Width: TX525 (Narrow Track) - 5.88” (14.9cm)
TX525 (Wide Track) - 9.5” (24.13cm)
Track Pitch: 3.45” (8.8cm)
Drive Wheel The drive wheels are single-piece, austempered ductile iron, squirrel cage castings. The
wheels are mounted directly onto the tapered shafts of the wheel motors.
Wheel Diameter: 11.63” (29.5cm)
No. of Teeth:eter 11
Road Wheels Constant track ground pressure is maintained by 20 ductile iron road wheels. The road
wheels each have a sealed bearing that are protected by a secondary dirt seal on the inside
and a gasketed steel cap on the outside.
