Toro TX525 - 14 Gpm Pump Assembly

HYDRAULIC SYSTEM
6-48 Rev. 000 TX525 Service Manual
14 gpm Pump Assembly
10. Install the snap ring into the pump cover (Fig. 1010). 2. Remove the driven gear from the bushing (Fig.
1012).
Fig 1010 PICT-2848a
Fig 1012 PICT-2850a
3. Remove the drive gear from the bushing (Fig. 1013).
Note: Lubricate all surfaces on reassembly.
1. Remove the bushing from the drive gear and driven
gear shafts (Fig. 1011).
Fig 1013 PICT-2851a
Fig 1011 PICT-2849a
