Toro TX525 - Air Cleaner Assembly & Muffler Assembly Installation; Air Cleaner Assembly Installation

ENGINE
4-24 Rev. 000 TX525 Service Manual
Air Cleaner Assembly & Mufer
Assembly Installation
Fortestingandserviceoftheinjectors,refertothe
KubotaServicemanual“KubotaD722/D902Tier2
DieselEngineServiceManual”(ToroFormNo.492-
4796)(Fig.0164).
Fig 0164 PICT-5252
1. Positiontheaircleanersothemountingbracket
holesalignwiththemountingholesintheengine
block.Usinga13mmsocket,install2newboltsand
washerssecuringtheaircleanerassemblytothe
engineblock(Fig.0165).
Fig 0165 PICT-5232
Air Cleaner Assembly Installation
2. Torquethe2boltsto19+2ft-lbs.(25.7+2.7Nm)
(Fig.0166).
Fig 0166 PICT-5335
