Toro TX525 - Alternator Mounting Styles

ENGINE
4-28 Rev. 000 TX525 Service Manual
Thethreemethodsofattachingthealternatorareillus-
tratedanddescribedbelow.
TX525 22319#270000001-270000555
 22320#270000001-270000711
 22333#270000001-270000422
 22334#270000001-270000426
Theenginegearcasehousingangeisthreaded(Fig.
0178).
Fig 0178 PICT-5564
TX525 22319#270000721&higher
 22320#270000886&higher
 22333#270000447&higher
 22334#270000437&higher
Theenginegearcasehousingangeisnotthreaded
(notpictured).
TX525 22319#270000556-270000720
 22320#270000712-270000885
 22333#270000423-270000446
 22334#270000427-270000436
Theenginegearcasehousingangeisthreadedandt
withbrackets(Fig.0179).
Fig 0179 PICT-9354
Alternator Mounting Styles
