ENGINE
4-21TX525 Service Manual Rev. 000
23. Filltheradiator.Referto“Checking,Adding&
BleedingtheEngineCoolant”onpage4-138.
24. Checkthehydraulicoillevel.Referto“Checkingthe
HydraulicFluid”onpage3-4.
25. Purgeairfromthehydraulicsystem.Referto“Purg-
ingAirProcedure”onpage9-19.
Mufer Assembly & Air Cleaner
Assembly Removal
Mufer Removal
Glow Plug, Fuel Injector Access
• Toservicethethreeglowplugsonthetopsideofthe
engine,themufermustberemoved.
• Toservice#1cylinderfuelinfectortheaircleaner
mustberemoved.
• Toservice#2and#3cylinderfuelinjectorthemufer
mustberemoved.
1. Positionthetractionunitonaatsurface.
2. Openthehood.
3. Raiseloaderarmsapproximately4”(10cm).Lock
theloaderarmintopositionusingtheloaderarm
lock.
4. Removerightandleftsidepanels.
5. Usinga3/8”socketcombination,loosentheengine
intakehoseclampandslidetheintakehosedown
offoftheairlterassembly(Fig.0154andFig.
0155).
Fig 0154 PICT-3259
Fig 0155 PICT-3261
