ENGINE
4-20 Rev. 000 TX525 Service Manual
19. Usinga1/2”socket,tightenthe4boltssecuringthe
grillassemblytotheframe(Fig.0150).
TX525,serial#280000001&higher,useangehead
bolts:
Fig 0150 PICT-5150
Fig 0152 PICT-5605
22. Positionthebreathertubeunderthegrillandinstall
thebreather(Fig.0153).
20. Checkthecoolingfanandshroudclearance.Adjust
thepositionoftheradiatorifnecessary.
21. Usinga9/16”socket,tightenthe2boltssecuring
theradiatortothegrillassembly(Fig.0151andFig.
0152).
TX525,serial#270000001-270999999,useboltsand
washers:
Fig 0153 PICT-5157
Fig 0151 PICT-5604
