ENGINE
4-19TX525 Service Manual Rev. 000
15. Slidegrillontotheframesothegrillbasesitsunder
theloaderstopsandthetopofthegrillsitsontop
oftheradiator.Leavethegrillinaslightlyforward
position.Theoverowtankmountingholesshould
bejustbeyondtherighthandbossontopofthe
radiatorassembly.Thiswillallowtheoverowbottle
assemblytobeinstalled(Fig.0146).
17. Install2boltsandnutssecuringtheoverowbottle
assemblytothegrillassembly(Fig.0148).
Fig 0146 PICT-5141a
Fig 0148 PICT-5145
18. Slidethegrillassemblybackaligningthemounting
holeswiththeholesintheframe.Looselyinstall4
boltssecuringthegrillassemblytotheframeandthe
2boltsandwasherssecuringthegrilltotheradiator
(Fig.0149).
16. Positiontheoverowtankbracketontothegrill
assembly(Fig.0147).
A. 4Grillassembly-to-framebolts
B. 2Grillassembly-to-radiatorboltsandwashers
A. Overowtankmountingholes
B. Righthandboss
Fig 0149 PICT-5146
Fig 0147 PICT-5143a
A
A
B
A
A
BB
