Toro TX525 - Alternator;Fan Belt

MAINTENANCE
3-26 Rev. 000 TX525 Service Manual
Fig 0071 g.3EEABAB1P017B
Alternator/Fan Belt
FanBeltTension:Deects0.28to0.35”(7to9mm)
whenthebeltispressedinthemiddleofthespan
(Fig.0071).
A. Deection
1. Stoptheengineandremovethekey.
2. Applymoderatethumbpressuretobeltbetweenthe
alternatorandcrankshaftpulleys.
3. Iftensionisincorrect,loosenthealternatormounting
boltsand,usingaleverplacedbetweenthe
alternatorandtheengineblock,pullthealternator
outuntilthedeectionofthebeltfallswithin
acceptablelimits.
A
Fig 0072 g.3EEABAB1P018A
A. Newbelt B. Wornbelt
4. Replacefanbeltifitiswornordamaged.Replace
thepulleyifthebeltgrooveiswornexcessively(Fig.
0072).
A
B
