17. Removethefrontradiatormount(Fig.0029). 19. Slidealengthof5/16”hoseontothepetcockdrain.
Placetheotherendofthehoseintoadrainpan.
Openthepetcockandremovetheradiatorcapto
draintheanti-freeze(Fig.0031).
Fig 0029 PICT-4971
Fig 0031 PICT-4974
20. Removethedrainhoseandclosethepetcock.
21. Usinga17mmwrench,removetheengineblock
coolantdrainplug(Fig.0032).
18. Tilttheradiator/oilcoolerassemblyforwardandlift
itoutoftheframesothatthepetcockdrainisabove
theframe(Fig.0030).
Fig 0032 PICT-8910
Fig 0030 PICT-4973
