10. Placeanabsorbenttowelundertheoilcoolerinlet
ttinglocatedonthelowerlefthandcorneroftheoil
cooler.
11. Usinga1-1/16”anda1-1/8”wrench,removetheoil
coolerinletlinefromtheoilcoolerinlettting(Fig.
0026).
14. Usinga1-1/16”anda1-1/8”wrench,removetheoil
cooleroutletlinefromtheoilcooleroutlettting(Fig.
0027).
Fig 0026 PICT-4965
Fig 0027 PICT-4968a
15. Capthehydrauliclineandttingsodebrisdoesnot
enterthesystem.
16. Usinga1/2”socket,removethe3boltssecuringthe
radiatormounttotheframe(Fig.0028).
12. Capthehydrauliclineandttingsodebrisdoesnot
enterthesystem.
13. Placeanabsorbenttowelundertheoilcooleroutlet
ttinglocatedontheupperrighthandcornerofthe
oilcooler.
Fig 0028 PICT-4969
