MAINTENANCE
3-20 Rev. 000 TX525 Service Manual
7. Disconnectthetwowires(blackandorange)from
thefuelsendingunitlocatedonthetopofthefuel
tank(Fig.0055).
9. Slidethe2fuelhoseclampsdownthefuellineaway
fromthefueltankttings(Fig.0057).
Fig 0055 PICT-4262a
Fig 0057 PICT-4264
8. Markthesuctionfuellineandtankttingwithan“S”
andthereturnfuellineandtankttingwithan“R”
(Fig.0056):
 S-Fuelsuctionline
 R-Fuelreturnline
Fig 0056 PICT-4263
6. Removethefueltankbracket(Fig.0054).
Fig 0054 PICT-5625
