ENGINE
4-97TX525 Service Manual Rev. 000
3. Torquethe6boltsto19+2ft-lbs.(00+00Nm)(Fig.
0442).
Fig 0442 IMG_8085
4. Routethedrivebeltaroundtheenginepulley(Fig.
0443).
Fig 0443 IMG_8086
5. Positionthetandempump/pumpmountassembly
andcouplertotheenginesothatthecouplerslides
ontotheenginegear(Fig.0444).
Fig 0444 IMG_8087
6. Usinga13mmsocket,install4boltssecuringthe
tandempump/pumpmountassemblytotheengine
(Fig.0445).
Fig 0445 PICT-5547a
