Toro TX525 - Page 210

ENGINE
4-157TX525 Service Manual Rev. 000
18. Removetherotorfromtheendframe(Fig.0675).
Fig 0675 PICT-8198
19. Removethewavewasherfromtherotor(Fig.0676).
Fig 0676 PICT-8203a
20. Usingastraightscrewdriver,removethebearing
coverfromthebearingontherotorshaft(Fig.0677).
Fig 0677 PICT-8204a
21. Usingapuller,removethebearingfromtherotor
shaft(Fig.0678).
Fig 0678 PICT-8206
