3. Looselyinstallthe2bolts,lockwashersandwashers
securingtheoppositeoilcoolermountingangeto
thetopsideoftheradiator(Fig.0104).
5. Positionthefanshroudontotheradiator/oilcooler
assembly(Fig.0106).
Fig 0104 PICT-5068
Fig 0106 PICT-5073
6. Positionthebackingplateontoshroud(Fig.0107).
4. Centertheoilcoolerontotheradiator(Fig.0105)
andprogressivelytighteneachofthe4boltsto
evenlysecuretheoilcoolertotheradiator.
Fig 0107 PICT-5085
Fig 0105 PICT-5084a
