Toro TX525 - Page 92

ENGINE
4-39TX525 Service Manual Rev. 000
2. Positionthefanmountspacertotheenginecoupler
(Fig.0217).
Fig 0217 PICT-5115
3. Securetheywheelsothatitcannotturn.Usea
6mmAllensockettoinstallthe3boltssecuringthe
fanmountspacertotheenginecoupler(Fig.0218).
Fig 0218 PICT-5114
4. Torquethe3boltsto19+2ft-lbs.(25.7+2.7Nm)
(Fig.0219).
Fig 0219 PICT-5117
5. Slidethecoolingfanontothefanmountspacer(Fig.
0220).
Fig 0220 PICT-5113a
