6-14 Qualitek mR Owner’s Guide
Hold Timer: A pass result requires a pass condition to be detected during the
Measure step time and held continuously for the set Hold time. A flashing
pass condition is indicated when Hold state is selected and normal result
outputs are set on completion of the step.
Pass Hold Duration: Used to enter the amount of time to hold timer for a pass
condition during the measure step. Use the arrow keys or virtual keyboard
to enter value.
Vent
Vent Step Control Option: The vent output may be disabled by tapping the vent
step label. Uncheck exhaust test part box and select Done. Next, set Vent Time to
zero.
Set the Vent time: Used to open the part under test to atmospheric pressure.
If the vent output is disabled, the test part may remain pressurized; use care
when disconnecting the test part.
