8-60 Phaser 7750 Printer Service Manual
LTD/HCF Feeder Paper-Select Switches
1. Remove the paper tray.
2. Reach inside the cabinet and disconnect the wire harness.
3. Reach inside the cabinet and remove the 1 screw that secures the paper-select
switch.
Universal Tray
Assembly
V
Universal Tray Paper
Select Switch (3X)
7750-154
