1-14
SPECIAL TOOLS
Damper rod holder (ø27)
90890-01423
Damping rod holder
YM-01423
4-84, 4-87
Fork seal driver
90890-01442
Adjustable fork seal driver (36–46 mm)
YM-01442
4-86, 4-86, 4-86
Rod puller
90890-01437
Universal damping rod bleeding tool set
YM-A8703
4-87
Rod puller attachment (M10)
90890-01436
Universal damping rod bleeding tool set
YM-A8703
4-87
Compression gauge
90890-03081
Engine compression tester
YU-33223
5-6
Valve spring compressor
90890-04019
Valve spring compressor
YM-04019
5-24, 5-28
Tool name/Tool No. Illustration
Reference
pages
YM-A8703
YM-A8703
90890-03081
YU-33223
